Configured for shaft vibration and position monitoring in mechanical protection layouts, the Bently Nevada 330881-BR-05-090-00-02 (330881-BR-05-090-00-02 Proximity Transducer) delivers direct physical housing and signal containment for industrial machinery.

Model Matrix And Suffix Breakdown

• Base Architecture: 330881 - PROXPAC XL Proximity Transducer
• Probe and Approvals Option: BR - No probe assembly included
• Standoff Adapter Option: 05 - 50 mm standoff adapter length
• Probe Penetration Option: 090 - 90 mm penetration depth
• Fittings Option: 00 - No fittings; two plugs and two washers
• Mounting Thread Option: 02 - 3/4-14 NPT thread connection

Hardware Specifications

Rotor Dynamics And Eddy-Current Transducer Performance

The transducer assembly utilizes eddy-current probe scaling to map mechanical clearance between internal sensor tips and rotating shaft targets. Proper system configuration requires strict gap voltage validation targeting a nominal center point between -9 VDC and -11 VDC. Rotor dynamics analysis relies on this high-frequency analog response to track displacement and vibration, utilizing cross-talk suppression and matched impedance cabling to maintain signal fidelity across industrial monitoring loops.

Ordering Information

• 1 x 330881-BR-05-090-00-02 PROXPAC XL Proximity Transducer Assembly (50 mm standoff adapter, 90 mm probe penetration, 3/4-14 NPT mounting thread, two plugs, two washers, without internal probe)

Field Installation Instructions

• Thread Sealing: Apply approved thread sealant or tape conforming to 3/4-14 NPT specifications to prevent leakage during high-pressure machinery operation.
• Mechanical Alignment: Secure the enclosure housing onto the machine casing, ensuring proper physical alignment and torque distribution to avoid distortion.
• Standoff Adjustments: Verify the 50 mm standoff adapter and 90 mm penetration parameters match internal clearance tolerances before finalizing mechanical lockdown.
• Port Sealing: Install the provided plugs and washers securely into unused auxiliary ports to maintain environmental integrity.

Frequently Asked Questions

• What is the primary function of the 330881-BR-05-090-00-02 assembly?

  It serves as a protective mechanical housing and mounting structure for proximity probes used in machinery condition monitoring.

• Does this specific part number include an internal probe?

  No, the option code indicates it ships without an internal probe component.

• What thread standard is utilized for mounting?

  The unit features a 3/4-14 NPT mounting thread configuration.

• What are the standoff and penetration specifications for this model?

  It incorporates a 50 mm standoff adapter and a 90 mm probe penetration depth.

• What fittings are included with the shipment?

  The package contains no external fittings, but includes two plugs and two washers for port sealing.

• Does the assembly require external electrical power?

  No, it is a passive mechanical enclosure that houses signal-carrying transducers energized by an external monitor or Proximitor sensor.

• What temperature limits govern the operational envelope?

  The structural assembly withstands thermal conditions ranging from -51 deg C up to +177 deg C.

• How should thread connections be sealed during installation?

  Standard industrial thread sealant rated for NPT fittings must be applied to ensure a pressure-tight seal against process environments.
