Configured for signal conditioning in proximity transducer systems, the Bently Nevada 330180-92-05 (330180-92-05 Proximitor Sensor) provides direct physical and electrical execution of probe-to-monitor signal translation within 3300 XL platform architectures.

Model Identification

  • Model: 330180

  • Part Number: 330180-92-05

  • Product Type: Proximitor Sensor

  • System Family: 3300 XL 8 mm Proximity Transducer System

Hardware Specifications

Parameter Specification
Model 330180-92-05
Brand Bently Nevada
Origin USA
Weight 0.24 kg
Shipping Dimensions 8.0 x 6.0 x 6.3 cm
Operating Temp Consult 3300 XL manual
Power Consumption System-dependent
System Range 9 meters (Total)

Mechanical Monitoring & TSI Integration

The 330180-92-05 Proximitor Sensor processes high-frequency signals from eddy-current probes to measure rotor displacement. Calibration of eddy-current probe scaling is required at the installation site to align the output voltage with the specific target material characteristics. Technicians must perform gap voltage validation to ensure the -10 VDC target midpoint is achieved for linear transducer response. The sensor design incorporates filtering for cross-talk suppression, ensuring that multi-probe installations do not experience signal interference during operation in complex rotor dynamics applications.

Ordering Info

  • One (1) 330180-92-05 Proximitor Sensor.

  • Technical documentation covering integration, wiring, and safety standards.

  • Mounting hardware for standard DIN-rail installation.

Field Installation Guidelines

  • Mounting: Secure the sensor to the DIN rail; ensure the housing is grounded to the cabinet instrument bus to maintain signal common.

  • Wiring: Terminate coaxial cabling from the probe and the extension cable to the sensor input terminals, maintaining impedance continuity.

  • Grounding: Utilize a star-ground configuration for all instrumentation signal shields to eliminate ground loop currents.

  • Verification: Confirm that the output voltage at the Proximitor "OUT" terminal matches the theoretical value based on the measured physical gap.

Frequently Asked Questions

  • Is the sensor compatible with all 3300 XL 8 mm probes? Yes, it is designed for use within the 3300 XL 8 mm Proximity Transducer System family.

  • What is the significance of the 9-meter range? The total system length (probe + extension cable) is calibrated to 9 meters to maintain correct signal impedance and frequency response.

  • Can this be mounted in an outdoor environment? The sensor must be protected within a NEMA-rated or IP-rated enclosure; it is not designed for direct exposure to elements.

  • Is the sensor field-configurable? No, the internal circuitry is factory-calibrated for specific transducer system lengths; do not modify or alter the cable length.

  • How do I troubleshoot a "Not OK" status? Verify input power, check for cable continuity, and perform a gap voltage check to ensure the probe tip is within the linear sensing range.

  • What is the frequency response? The sensor is capable of high-frequency operation to track rapid shaft movements and vibration transients accurately.

  • Is hot-swapping supported? Hot-swapping is dependent on the monitoring system configuration; consult the 3500 system or rack manual before removal.

  • What mounting options are available? The unit supports standard DIN-rail mounting for integration into control cabinet backplanes or racks.
