Configured for contactless displacement monitoring in 3500 Machinery Protection Systems, the Bently Nevada 330101-00-40-20-12-05 (330101 Proximity Probe) provides direct physical/electrical execution. The component converts the relative distance between the probe tip and a metallic target into a proportional analog voltage signal. This electrical output is routed to an external Proximitor sensor, enabling high-frequency evaluation of shaft vibration, axial position, and rotor dynamics.

Model Configuration Matrix

• 330101: 3300 XL 8 mm Proximity Probe (3/8-24 UNF thread, non-armored)
• -00: Unthreaded Length option (0.0 inches of unthreaded probe sleeve)
• -40: Case Total Length option (4.0 inches of total threaded case length)
• -20: Total Length option (2.0 meters total system length)
• -12: Connector option (Miniature coaxial Click-Loc connector with fluid barrier)
• -05: Agency Approval option (Multiple international intrinsic safety certifications)

Hardware Technical Specifications

Rotor Dynamics & Eddy-Current Precision

The performance of the 3300 XL system relies on accurate eddy-current probe scaling to ensure vibration data remains representative of machine health. During the setup phase, gap voltage validation is performed to achieve a -10 VDC target at the mid-point of the linear operating range. This ensures the signal swing is centered within the input range of the monitor module. Additionally, field technicians must prioritize cross-talk suppression by maintaining adequate separation between probe tips, which prevents the excitation fields of adjacent sensors from distorting phase-angle and amplitude measurements.

Ordering & Shipment Contents

• Core Hardware: One (1) 330101-00-40-20-12-05 proximity probe.
• Mechanical Hardware: Two (2) 3/8-24 UNF-2A locking nuts.
• Environmental Accessories: One (1) silicone connector protector sleeve.
• Compliance Documentation: One (1) factory calibration and certification slip.

Field Mounting Guidelines

• Thread Engagement: Ensure a minimum of five (5) full thread turns are engaged in the mounting bracket to secure the probe position under vibration.
• Gap Setting: Verify the static gap using a feeler gauge to ensure the probe tip does not contact the shaft during rotor thermal expansion or transient mechanical deflection.
• Cable Management: Secure the coaxial lead to a static structural member at frequent intervals to minimize cable whip and prevent connector strain.
• Shield Grounding: Ground the coaxial shield at only one point—the monitor rack terminal—to prevent ground loops that introduce electrical noise into the signal chain.

Transit & Logistics

• Delivery time: 2-7 days when payment finish.
• Shipping: Dispatched via DHL, FEDEX, or UPS.
• Protection: Components are secured in anti-static industrial packaging and high-impact shock-absorbent materials.

Technical FAQ

• What is the consequence of exceeding the 2.0 mm linear range?

  Exceeding the range causes the signal to deviate from the 7.87 V/mm linear slope, leading to distorted vibration waveforms and inaccurate amplitude measurement.

• Is the 330101 probe compatible with older 3300 8mm extension cables?

  No, the 3300 XL system requires matched components to maintain system impedance and signal integrity. Mixing with older series violates calibration standards.

• What defines the "NOT OK" status in the 3500 monitoring system?

  A "NOT OK" status occurs when the Proximitor voltage falls below -1 VDC or rises above -21 VDC, indicating an open circuit, short circuit, or probe failure.

• Does the probe cable length affect the Proximitor signal?

  Yes, the system is calibrated for specific total lengths. Altering the cable length without corresponding system recalibration introduces unacceptable measurement errors.

• How is probe tip damage detected during operation?

  Damage to the tip changes the resonance frequency of the coil, which is detected by the Proximitor as a deviation in bias voltage, triggering a channel fault.

• Can the probe be mounted in a non-metallic housing?

  The probe requires a conductive backing to function; if mounting in non-metallic material, a metal insert or sleeve must be used to provide the correct eddy-current path.

• Is it possible to field-calibrate the probe for different shaft materials?

  The 7.87 V/mm scaling is specific to AISI 4140 steel. Calibrating for different metals requires a multi-point verification curve and specialized system gain adjustments.

• What is the purpose of the silicone connector protector?

  The protector prevents conductive machine oil or water from bridging the coaxial connector contacts, which would otherwise lead to signal attenuation or system instability.
