1MRK000508-CDr03 ABB Control Board | New & Original Stock

1MRK000508-CDr03 ABB Control Board Relion Series

ABB

1MRK000508-CDr03 ABB Control Board Relion Series

SKU: 1MRK000508-CDr03

In Stock

Dimensions: 23.3 x 16.6 x 2.5 cm
Country of origin: USA
Payment: T/T, Western Union
Shipping port: Xiamen

Categories : ABB, ABB Power Supplies, All Products, DCS & Control Processors

Tags : ABB Relion Protection Relays, Control Boards, Protection And Control Systems

1 years warranty

Delivery time: 3-7 business days

Free 30 days return

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

Configured for processing digital field signals and control logic execution in ABB Relion protection and control systems, the ABB 1MRK000508-CDr03 (1MRK000508 Control Board) provides direct electrical execution. The board integrates a 32-bit RISC processor, onboard memory resources, digital I/O interfaces, and isolated circuitry for data acquisition, event handling, and relay control functions within Intelligent Electronic Device (IED) architectures.

Model Identification

The supplied product corresponds to a fixed hardware configuration identified as 1MRK000508-CDr03. No official suffix matrix or variant breakdown is provided within the available technical data.

Technical Specifications

Parameter	Specification
Model	1MRK000508-CDr03
Spare Model	1MRK000007-7
Brand	ABB
Product Type	Control Board
Origin	Sweden
Manufacturer	ABB
Weight	0.54 kg
Shipping Dimensions	23.3 x 16.6 x 2.5 cm
Processor	32-bit RISC
Clock Speed	100 MHz
RAM	128 MB
Flash Memory	64 MB
Operating Voltage	24-250 V DC/AC
Digital Inputs	24 V DC
Digital Outputs	5 A @ 250 V AC
Isolation Voltage	2 kV AC
Power Consumption	8 W typical
Operating Temp	-40 to +70 deg C
Storage Temp	-40 to +85 deg C
Humidity	5-95% non-condensing
Tariff Code	8537101190
Place of Shipment	Xiamen, China

Firmware Flash Compatibility

The onboard 64 MB flash memory stores operational firmware and configuration data used by the control platform. Firmware updates should be performed only with ABB-approved revisions intended for the associated Relion device family. Prior to replacement or upgrade, compatibility between the control board revision and installed firmware package should be verified to prevent startup faults or configuration mismatches.

Included Items

ABB 1MRK000508-CDr03 Control Board
Industrial protective packaging
No field cables, software, manuals, terminal accessories, or additional hardware unless separately specified

Installation Recommendations

Remove all system power sources before inserting or removing the control board.
Observe ESD protection procedures when handling exposed PCB assemblies.
Verify operating voltage compatibility before energizing the system.
Maintain separation between low-voltage signal wiring and power conductors.
Ensure proper grounding of the cabinet and shielding of connected signal cables.
Confirm connector engagement and mechanical retention before commissioning.
Avoid installation in environments exceeding the specified temperature and humidity limits.

Logistics & Packaging

Delivery time: 2-7 days when payment finish.

Shipment is typically arranged through DHL, FedEx, or UPS. The module is packed using anti-static industrial packaging materials with protective cushioning to reduce mechanical stress during transportation and storage.

Technical FAQ

Q: Does the 1MRK000508-CDr03 support hot swapping?
A: Hot-swap capability is not specified in the available technical data. Module insertion or removal should be performed with system power removed.

Q: What type of processor is installed on the board?
A: The module utilizes a 32-bit RISC processor operating at 100 MHz.

Q: What isolation level is provided between the board and chassis?
A: The specified isolation voltage is 2 kV AC.

Q: What output load can the digital outputs switch?
A: The digital outputs are rated for up to 5 A at 250 V AC.

Q: What environmental conditions are supported during operation?
A: The specified operating temperature range is -40 to +70 deg C with 5-95% non-condensing humidity.
