1784-PCIC Allen-Bradley ControlNet PCI Communication Card FLEX I/O Series

SKU: 1784-PCIC
Categories : All Products
In Stock
  • Dimensions: 23 x 22.5 x 4 cm
  • Country of origin: USA
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The Allen-Bradley 1784-PCIC, also cataloged as the 1784-PCIC ControlNet PCI Communication Card, operates as a dedicated hardware component for PC-based ControlNet network communication within Allen-Bradley industrial control platforms.

Model Configuration Details

The 1784-PCIC is a PCI communication interface card designed to provide ControlNet connectivity between a personal computer and Allen-Bradley automation systems. The card supports ControlNet messaging, PLC-5 communication functions, and VNET bus messaging through PCI-based computer architectures.

The module supports installation in compatible PCI and PCI-X expansion slots and provides ControlNet network access through a BNC interface.

Hardware Specifications

Parameter Specification
Model 1784-PCIC
Brand Allen-Bradley
Product Type ControlNet PCI Communication Card
Series FLEX I/O Series
Origin USA
Weight 0.4 kg
Shipping Dimensions 23 cm x 22.5 cm x 4 cm
Operating Temp Not specified
Power Consumption 3.5 W
Power Supply 5 VDC, 700 mA
Communication Interface ControlNet BNC
PC Interface PCI / PCI-X
PCI Compatibility 5 V and 3.3 V PCI, 32-bit and 64-bit PCI
Network Connector RJ45 port interface
Isolation Voltage 50 V
Communication Function ControlNet messaging and PLC-5 VNET bus messaging

Industrial Network Communication Characteristics

The 1784-PCIC provides PC-based access to ControlNet deterministic networks through PCI bus communication. The card supports data exchange between computer applications and Allen-Bradley control systems using ControlNet messaging services.

Allen-Bradley industrial communication platforms use dedicated network interfaces to maintain data exchange between controllers, programming systems, and distributed I/O devices. The 1784-PCIC enables integration of PC applications with ControlNet-connected PLC systems.

The module uses PCI bus communication architecture and requires compatible software drivers for configuration and application-level communication. Firmware and driver compatibility must match the installed operating environment.

ControlNet Network Interface Operation

The 1784-PCIC provides a physical ControlNet connection through a BNC interface. Network wiring should maintain correct coaxial cable termination, shielding, and grounding practices.

The PCI interface supports installation in multiple computer expansion architectures, including 5 V PCI, 3.3 V PCI, 32-bit PCI, 64-bit PCI, and PCI-X slots.

Ordering Information

  • 1 x Allen-Bradley 1784-PCIC ControlNet PCI Communication Card
  • PCI interface card assembly
  • ControlNet BNC communication interface
  • RJ45 communication interface
  • Configuration software, drivers, and manuals are not included unless specified

Field Installation Guidelines

PCI Slot Installation

  • Shut down the host computer before installing the communication card.
  • Confirm PCI slot voltage compatibility before insertion.
  • Secure the card bracket to maintain mechanical stability.

ControlNet Connection

  • Connect the ControlNet coaxial cable to the BNC interface.
  • Maintain proper cable shielding and termination practices.
  • Avoid routing communication cables parallel with high-voltage power conductors.

Configuration Requirements

  • Install compatible communication drivers before application setup.
  • Verify ControlNet node configuration parameters.
  • Confirm PC communication software compatibility with the installed card revision.

Frequently Asked Questions

  • What is the primary function of the 1784-PCIC?

The 1784-PCIC provides a PCI-based interface between a personal computer and ControlNet industrial communication networks.

  • Which network does the 1784-PCIC support?

The card supports Allen-Bradley ControlNet communication through a dedicated BNC network interface.

  • What type of computer slots are compatible?

The module supports 5 V and 3.3 V PCI slots, including 32-bit, 64-bit PCI, and PCI-X architectures.

  • What power supply does the card require?

The 1784-PCIC operates from the computer PCI bus power supply with a specified 5 VDC input.

  • Does the card provide electrical isolation?

Yes. The module specification includes a 50 V isolation voltage rating.

  • Can the 1784-PCIC communicate with PLC-5 systems?

Yes. The card supports ControlNet communication functions including PLC-5 related messaging applications.

  • What connector is used for ControlNet communication?

The ControlNet network connection uses a BNC interface for coaxial communication wiring.

  • Is hot swapping supported for this PCI card?

No. The computer should be powered down before installation or removal of the PCI communication card.
