The Allen-Bradley 1783-MS06T, also cataloged as the 1783-MS06T Managed Ethernet Switch, operates as a dedicated hardware component for industrial Ethernet communication and network traffic management within Stratix 8000 network systems.

Model Identification

The 1783-MS06T is a Stratix 8000 managed switch with six Ethernet ports designed for industrial network infrastructure. The switch provides four copper ports and two combo ports supporting copper, fiber, SFP, and Power over Ethernet (PoE) expansion configurations.

Hardware Specifications

Industrial Ethernet Network Features

The 1783-MS06T belongs to the Allen-Bradley Stratix managed switch family and provides Ethernet switching functions for industrial automation networks. It manages connected devices through configurable network communication paths and supports copper and fiber-based connectivity options.

The Stratix platform is designed for integration with Allen-Bradley control architectures. Ethernet/IP deterministic network configuration, switch management parameters, and firmware compatibility must be verified according to the installed automation system requirements.

Network Communication Architecture

The Stratix 8000 series supports industrial Ethernet infrastructure with managed switching functions, allowing network segmentation, device communication control, and expansion through compatible interface options.

The switch supports industrial control environments requiring Ethernet/IP communication paths between PLC controllers, I/O modules, HMIs, and other Ethernet-enabled devices. Proper network topology design is required to maintain communication performance and system stability.

Ordering Information

• 1 x Allen-Bradley 1783-MS06T Stratix 8000 Managed Ethernet Switch
• 1 x Six-port managed switch hardware unit
• 1 x Integrated copper and combo port interface configuration
• SFP modules, fiber accessories, PoE components, and mounting accessories are ordered separately when required

Field Installation Guidelines

Network Connection

• Verify Ethernet cable type and connector specifications before installation.
• Separate communication wiring from high-voltage power cables to reduce electromagnetic interference.
• Confirm fiber and copper interface compatibility before connecting field devices.

Mounting Requirements

• Install the switch according to industrial panel or enclosure requirements.
• Ensure sufficient airflow around the equipment during operation.
• Connect protective grounding according to the control cabinet design.

Configuration Checks

• Verify switch firmware compatibility with the connected control system.
• Configure network parameters before connecting production devices.
• Confirm Ethernet/IP communication paths after installation.

Frequently Asked Questions

• What network series does the 1783-MS06T belong to?

The 1783-MS06T is part of the Allen-Bradley Stratix 8000 managed switch family for industrial Ethernet communication.

• How many Ethernet ports are available?

The switch provides six ports, including four copper ports and two combo ports.

• Does the switch support fiber connections?

Yes. The combo ports support expansion options including fiber and SFP interfaces.

• Can the switch support Power over Ethernet?

The product specification lists PoE as an available expansion option through compatible interfaces.

• Is the 1783-MS06T a managed switch?

Yes. The unit is classified as a managed Ethernet switch with configurable network functions.

• Can this switch be installed in an industrial control panel?

Yes. The switch is designed for industrial automation network installation with suitable enclosure protection.

• Does the switch support Ethernet/IP networks?

The Stratix 8000 platform is designed for industrial Ethernet applications including Ethernet/IP communication architectures.

• Is hot swapping supported during operation?

Installation or replacement should be performed with proper power isolation unless the complete system design specifically supports live replacement procedures.
