Configured for seismic vibration monitoring in industrial control platforms, the Bently Nevada 177230-01-02-CN (177230 Seismic Transmitter) provides direct physical signal transduction of casing vibration through an industry-standard 4-20 mA loop-powered interface.

Hardware Specifications

Rotor Dynamics and Signal Conditioning

The 177230 Seismic Transmitter utilizes a ceramic/shear sensing element to convert mechanical acceleration into a calibrated 4-20 mA signal proportional to velocity. Successful deployment requires rigid mounting to the machine casing to ensure the transducer resonant frequency remains significantly higher than the frequency range of interest. By providing a raw vibration signal output, the transmitter allows for on-site verification and external diagnostics. Proper grounding and cable shielding are required to maintain signal-to-noise ratios, particularly in environments with high electromagnetic interference.

Ordering Information

• 1 x 177230-01-02-CN Seismic Transmitter unit.

• 1 x Regulatory compliance documentation.

Field Installation Guidelines

• Mechanical Mounting

• Secure the transmitter to a flat, rigid surface on the machine casing using the provided mounting stud.

• Ensure the mounting interface is free of paint or oxidation to maintain high-frequency coupling.

• Electrical Loop

• Connect the transmitter to a 4-20 mA current loop. Ensure the supply voltage is adequate to overcome the loop impedance of the receiving PLC or DCS analog input card.

• Shield the interconnecting cabling to prevent noise coupling; ground the shield only at the control system end.

Frequently Asked Questions

• What is the output signal format?

  The transmitter provides a 4-20 mA loop-powered output proportional to the measured velocity, as well as a raw vibration signal for external analysis.

• Can the device be used for displacement measurement?

  No, the 177230 is a seismic velocity transmitter; it measures casing-to-ground motion, not shaft-to-casing relative displacement.

• What is the impact of transverse sensitivity?

  Transverse sensitivity is limited to less than 5%, ensuring that vibration along axes perpendicular to the primary sensing axis does not cause significant measurement error.

• Does this device require an external power supply?

  The device is loop-powered via the 4-20 mA signal path; no additional DC power supply is required at the transmitter location.

• Why is the settling time specified?

  Settling time defines the period required for the output signal to stabilize within 2% of its final value following a step change in measured vibration.

• Is the transmitter field-calibrated?

  The transmitter is factory-calibrated. Field verification is limited to checking the loop current against expected vibration levels using the raw output signal.

• What is the purpose of the mounted resonant frequency?

  The > 12 kHz mounted resonant frequency ensures the sensor does not introduce its own mechanical resonance into the 3 Hz to 1 kHz measurement range.

• Can the transmitter be hot-swapped?

  Yes, as a loop-powered device, it can be disconnected from the loop, provided the monitoring system is placed in a bypass or maintenance mode.
