The Allen-Bradley 1747-BSN, also cataloged as the 1747-BSN Backup Scanner Module, operates as a dedicated hardware component for remote I/O scanning and controller backup communication within SLC 500 DH+ network systems.

Model Identification

The 1747-BSN Backup Scanner Module provides SLC 500 remote I/O communication through DH+ and RS-232 interfaces. The module operates from a 5 VDC backplane supply and manages backup scanner functions for redundant control configurations.

Hardware Specifications

Parameter	Specification
Model	1747-BSN
Brand	Allen-Bradley
Product Type	Backup Scanner Module
Series	SLC 500
Origin	USA
Weight	0.32 kg
Shipping Dimensions	3.5 cm x 13 cm x 14.5 cm
Operating Temp	Not specified
Power Consumption	500 mA at 5 VDC
Supply Voltage	5 VDC
Communication Interface	RS-232, DH+ (Data Highway Plus)
Remote I/O Function	Remote I/O Scanner
Communication Speed	57.6 kbps
Connector Type	3-pin Phoenix-style terminal block
Tariff Code	8537101190

DH+ Network Communication Features

The 1747-BSN uses Allen-Bradley Data Highway Plus communication architecture for SLC 500 backup scanner applications. The module exchanges controller and I/O information through configured DH+ network communication paths.

The RS-232 interface provides serial communication capability for supported external connections. The module operates through the SLC 500 backplane and requires correct chassis installation and communication parameter configuration.

Ordering Information

1 x Allen-Bradley 1747-BSN Backup Scanner Module
1 x Integrated communication interface assembly
1 x Phoenix-style terminal block connector
Compatible SLC 500 chassis and communication accessories are specified separately

Installation Guidelines

Module Mounting

Install the module in an SLC 500 chassis slot with compatible backplane connection.
Remove chassis power before module insertion or removal.
Confirm the module seating position before restoring system power.
Check connector alignment to prevent terminal damage.

Communication Wiring

Route DH+ and RS-232 communication cables separately from high-voltage wiring.
Apply proper cable shielding and grounding practices for serial communication lines.
Verify communication node settings before connecting the module to an active network.
Confirm terminal block wiring according to the system communication design.

Frequently Asked Questions

What is the primary function of the 1747-BSN?

The 1747-BSN is a backup scanner module designed for SLC 500 remote I/O communication and controller backup applications.

Which communication networks are supported by the module?

The module supports DH+ Data Highway Plus communication and an RS-232 serial interface.

What voltage does the 1747-BSN require?

The module operates from a 5 VDC SLC 500 backplane power supply.

What is the current consumption of the module?

The specified current consumption is approximately 500 mA from the 5 VDC supply.

Does the 1747-BSN contain PLC control logic?

No. The module performs scanner and communication functions and does not execute user control programs.

What communication speed is supported?

The module supports a DH+ communication rate of 57.6 kbps.

What connector type is used on the 1747-BSN?

The module uses a 3-pin Phoenix-style terminal block connector for field connections.

Can the module be installed without removing power?

No. Standard SLC 500 installation procedures require power removal before module installation or replacement.
