Configured for solid-state motor starting and pump control, the Allen-Bradley 150-F970NBEB (150-F970 Smart Motor Controller) provides three-phase AC motor control for high-current applications.

Model Identification

The supplied data identifies 150-F970NBEB as a Bulletin 150 solid-state Smart Motor Controller. The available information does not provide a verified manufacturer suffix decoding table, so individual suffix characters are not assigned specific functions.

Hardware Specifications

Solid-State Motor Control Characteristics

The 150-F970NBEB uses solid-state switching for motor starting rather than a conventional mechanical contactor as the primary starting element. Its stated 970 A rating and 800 HP motor rating place it in the high-current Bulletin 150 controller range.

The supplied documentation identifies a three-phase AC input with a 50/60 Hz operating frequency. The product information lists 200-460 VAC, while the detailed specification lists 200-480 VAC. The applicable voltage should therefore be verified against the controller nameplate and installation documentation before connection.

Ordering Information

• 1 x Allen-Bradley 150-F970NBEB Smart Motor Controller
• 1 x Bulletin 150 solid-state controller assembly
• 1 x Open-enclosure controller configuration
• No additional accessory kit or installation hardware is identified in the supplied product data.

Installation and Wiring Guidelines

• Install the controller in an enclosure suitable for the specified open-enclosure construction.
• Confirm the actual motor full-load current before connecting the controller to the motor circuit.
• Verify the incoming three-phase voltage and frequency against the controller nameplate.
• Confirm the control circuit voltage before applying the control supply.
• Maintain physical separation between power conductors and low-level control wiring where practical.
• Use appropriately rated conductors, terminals, disconnect devices, and overcurrent protection for the installation.
• Connect protective grounding according to the applicable electrical installation standard.
• Keep control wiring away from high-current switching conductors to reduce conducted electrical interference.
• Verify motor phase sequence and all control interlocks before energizing the motor.
• Do not treat the stated shipping dimensions as the required installation clearance because enclosure and service-clearance data were not supplied.

Frequently Asked Questions

• What type of controller is 150-F970NBEB?
  It is a Bulletin 150 solid-state Smart Motor Controller configured as a soft starter for three-phase AC motor applications.
• What is the rated current?
  The supplied product information specifies a 970 A controller rating.
• What motor rating is specified?
  The product information identifies an 800 HP motor rating for this controller configuration.
• What input voltage is specified?
  The supplied data lists 200-460 VAC and also gives 200-480 VAC in the detailed specification. Verify the nameplate before installation.
• What control voltage does it use?
  The detailed specification states 100-120 VAC. The product information separately lists 110/120 VAC.
• Is the controller intended for three-phase power?
  Yes. The supplied specification identifies a three-phase AC input operating at 50/60 Hz.
• Does the supplied data specify operating temperature?
  No. An operating-temperature range is not provided and should not be inferred without the applicable manufacturer documentation.
• What enclosure type is specified?
  The controller is identified as an open-enclosure configuration. Installation must therefore provide suitable enclosure and environmental protection.
