Configured for high-current three-phase motor soft starting and controlled torque acceleration in industrial power control enclosures, the Allen-Bradley 150-F780NBE (150-F780 Solid-State Soft Starter) provides direct physical/electrical execution. The internal power structure handles continuous full-load operating currents up to 780 A across main line supply voltages from 200 to 480 VAC. Silicon-controlled rectifier (SCR) gate triggering modulates output phase angles to regulate starting current spikes, protecting motor windings and mechanical power transmission components during acceleration cycles.

Catalog Designation & Parameter Mapping

• 150-F: Specifies the Bulletin 150 SMC Flex solid-state soft starter controller platform.
• 780: Designates the 780 A nominal operational current rating for standard inline load wiring.
• N: Standard open enclosure structural construction (IP00 rated) for cabinet integration.
• B: Operating main input line voltage specification of 200...480 VAC, 3-Phase, 50/60 Hz.
• E: Control circuit operating power voltage rating designated for 100...120 VAC (50/60 Hz).
• Standard: Base controller hardware assembly without factory-installed option card modules.

Physical and Operating Parameters

Network Communication & Backplane Protocol Execution

The soft starter links directly to Allen-Bradley ControlLogix and CompactLogix programmable automation controllers through optional DPI communication adapters. Operating over EtherNet/IP deterministic networks, the controller cyclically broadcasts line currents, operating thermal percentages, and hardware status parameters. Microprocessor firmware flash compatibility ensures synchronized SCR firing pulses across all three power phases, reducing supply voltage sags and optimizing I/O density scaling during network-triggered start or stop commands.

Itemized Dispatch List

• 1 x Allen-Bradley 150-F780NBE SMC Flex Soft Starter Module
• 1 x Set of Main Power Terminal Protective Barriers
• 1 x Panel Cutout and Hole Placement Mounting Sheet
• 1 x Printed Engineering Installation Manual

Field Wiring & Enclosure Installation Guidelines

• Cabinet Orientation and Clearances
  • Secure the chassis vertically against a bare metal, unpainted grounding panel inside an IP54 enclosure.
  • Provide a minimum vertical clearance of 150 mm both above and below the starter frame for unhindered air convection.
• Conductor Routing and Grounding
  • Route low-voltage 110/120 VAC control wiring in separate metal raceways away from 3-phase line power cables.
  • Connect the primary protective earth grounding lug directly to the central panel enclosure earth ground bar.

Technical Questions and Answers

• What specific control voltage does the 150-F780NBE terminal block accept?

  The control terminals require a single-phase supply voltage rated at 100...120 VAC at 50 Hz or 60 Hz.

• What is the continuous operational current capacity of this soft starter model?

  The unit provides a continuous full-load current rating of 780 A across 200...480 VAC 3-phase power lines.

• Does the 150-F780NBE feature integrated bypass contactors?

  Yes, internal bypass contactors engage after motor acceleration is complete to reduce heat generation across power SCRs.

• Can the internal operating firmware be flashed via communication networks?

  Yes, onboard logic supports firmware flash compatibility via DPI adapters using standard industrial network tools.

• What environment requires an additional enclosure for the 150-F780NBE?

  Because the chassis is an Open IP00 frame design, it must be installed inside a protective enclosure for all industrial uses.

• How does the unit monitor thermal overload conditions on connected motors?

  Embedded electronic overload algorithms calculate thermal capacity based on measured phase currents and programmed motor parameters.

• Are signal terminals galvanically isolated from internal power circuits?

  Yes, internal control board transformers and optocouplers isolate low-voltage control terminals from line-voltage power circuits.

• How is a hardware fault condition reset on this controller?

  Faults are cleared by sending a reset signal across terminal logic inputs, cycling control voltage power, or issuing a network reset command.
