150-F43NBRD Allen-Bradley Bulletin 150 SMC Flex Smart Motor Controller
Allen-Bradley

150-F43NBRD Allen-Bradley Bulletin 150 SMC Flex Smart Motor Controller

SKU: 150-F43NBRD
Categories : All Products
In Stock
  • Dimensions: 7.8 x 24 x 21.8 cm
  • Country of origin: USA
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The Allen-Bradley 150-F43NBRD serves as the primary 150-F43 Solid-State Soft Starter utilized to execute controlled three-phase induction motor acceleration and integrated braking operations across industrial power network platforms. It operates as an electronic control assembly rated for continuous currents up to 43 A on main supply voltages ranging from 200 to 480 VAC. Microprocessor-governed silicon-controlled rectifier (SCR) firing circuits modulate phase angles to control voltage ramp-up, limiting starting inrush current and preventing mechanical drive system shock during motor startup and deceleration.

Suffix Code Technical Breakdown

  • 150-F: Identifies the Bulletin 150 SMC Flex solid-state soft starter controller family.
  • 43: Represents the 43 A nominal continuous current rating for standard inline load wiring.
  • N: Specifies an Open Enclosure IP00 construction designed for panel integration.
  • B: Denotes an input line operational voltage parameters of 200...480 VAC, 3-Phase, 50/60 Hz.
  • R: Designates a low-voltage control power supply rating of 24 VAC/DC.
  • D: Factory-installed internal option module dedicated to braking control and Smart Motor Braking (SMB) routines.

Technical and Physical Specifications

Parameter Specification
Model 150-F43NBRD
Brand Allen-Bradley
Origin USA
Weight 2.06 kg
Shipping Dimensions 7.8 x 24 x 21.8 cm
Operating Temp 0 to +50 deg C
Power Consumption 50 W (Control Logic)
Rated Operational Current 43 A
Motor Power Rating 30 HP @ 460 VAC (7.5-30 HP range)
Input Line Voltage 200...480 VAC, 3-Phase, 50/60 Hz
Control Circuit Voltage 24 VAC/DC
Construction Protection Open (IP00)

Communication Architecture & Backplane Bus Execution

The soft starter interfaces directly with Allen-Bradley ControlLogix and CompactLogix systems using optional DPI fieldbus modules. Connecting over EtherNet/IP deterministic networks enables real-time transmission of motor operating parameters, phase current averages, and hardware fault diagnostic codes. Integrated microprocessor logic maintains strict firmware flash compatibility across option cards, ensuring microsecond-accurate SCR firing pulses and stable I/O density scaling during network-triggered start, stop, or braking sequences.

Package Delivery Contents

  • 1 x Allen-Bradley 150-F43NBRD Solid-State Soft Starter
  • 1 x Factory-Integrated Braking Option Module
  • 1 x Terminal Cover Shield Set
  • 1 x Mechanical Mounting and Electrical Connection Sheet

Installation Rules & Electrical Layout

  • Enclosure Mounting Protocols
    • Mount the chassis in a vertical orientation onto a flat, conductive metal panel inside an IP54 or NEMA-rated enclosure.
    • Provide a minimum vertical clearance of 150 mm above and below the chassis for unimpeded air convection cooling.
  • Grounding & Wiring Practices
    • Route low-voltage 24 VAC/DC control wiring separate from main 3-phase line and load power conductors.
    • Bond the frame ground connection directly to the central electrical panel earth ground bus using a low-impedance copper jumper.

Frequently Asked Questions

  • What control power input does the 150-F43NBRD require?

    The control terminals require a 24 VAC/DC low-voltage supply to power internal microprocessor logic and gate drive circuits.

  • What function does the D suffix option provide in this soft starter?

    The D suffix option designates a factory-installed braking control module enabling Smart Motor Braking (SMB) and controlled stopping.

  • Can this soft starter unit be used in outdoor environments without protection?

    No, the unit features an Open IP00 frame design and must be installed inside a suitable protective panel cabinet.

  • How does the starter reduce heat build-up during full-speed motor operation?

    Integrated bypass contactors close automatically once full output voltage is reached, bypassing the SCRs to reduce thermal dissipation.

  • Are firmware updates supported over network connections?

    Yes, onboard controller logic features firmware flash compatibility via DPI fieldbus interface cards.

  • What primary protective limits are built into the controller logic?

    It features electronic motor thermal overload, phase current unbalance monitoring, shorted SCR detection, and internal over-temperature tripping.

  • Are low-voltage control signals isolated from the line power circuit?

    Yes, internal control transformers and optocouplers provide complete galvanic isolation between line power and 24 VAC/DC control terminals.

  • How is a hardware fault condition reset on this controller?

    Faults can be cleared by applying a signal to the hardware reset terminal, cycling control power, or issuing a software command over the network.
