Product Overview

The 136294-01 is a high-performance Process Variable I/O module engineered for the Bently Nevada 3500/62 monitoring system. This module is specifically designed to integrate non-vibration parameters—such as fluid pressure, flow rates, gas levels, and temperatures—into the machinery protection environment. Featuring integrated internal terminations, the 136294-01 streamlines rack wiring by allowing field sensors to connect directly to the module. Its primary advantage lies in its high-voltage galvanic isolation, which filters out industrial electrical noise and prevents ground loops from compromising the accuracy of critical process data.

Performance Architecture and Hardware Specifications

• Signal Interface: 4 to 20 mA DC (Input and Output)

• Module Type: Isolated I/O with Internal Terminations

• Measurement Accuracy: ±0.25% of full scale

• Repeatability: ±0.1% of full scale

• Isolation Rating: 500 volts (Galvanic)

• Transient Protection: Up to 10 kV immunity

• Power Usage: 7.0 Watts (Typical)

• Physical Weight: 2.0 kg (4.41 lbs)

• Dimensions: 241.3 mm x 24.4 mm x 163.1 mm (9.50 in x 0.96 in x 6.42 in)

• Noise Suppression: 500 mV peak immunity

Core Industrial Deployment Scenarios

The 136294-01 is utilized across heavy industries where secondary process data is vital for a comprehensive machinery health profile. Key applications include:

• Lube Oil Systems: Monitoring oil pressure and flow rates in high-speed turbine bearings to ensure proper lubrication.

• Hydroelectric Power: Tracking reservoir levels and gate positions to correlate with turbine vibration data.

• Natural Gas Compression: Integrating suction and discharge pressure readings into the 3500 rack for automated alarm triggering.

• Chemical Processing: Monitoring reactor temperatures and flow variables that directly impact the mechanical stability of rotating mixers or agitators.

FAQ

Q: What is the benefit of "Internal Terminations" on the 136294-01 module?

A: Internal terminations allow the 4-20 mA field wires to be secured directly to the screw terminals on the module itself. This eliminates the need for external terminal blocks and additional cabling, saving space in the control cabinet.

Q: Does the 500V isolation protect against lightning strikes?

A: While the 10 kV transient immunity provides significant protection against power surges and spikes, it is not a substitute for primary lightning protection. The isolation is primarily intended to block electrical noise and ground loops.

Q: Can this module power a 2-wire transmitter?

A: Yes, the 3500/62 system is designed to interface with standard industrial transmitters, though you should verify the specific wiring diagram to ensure the module or an external source is providing the loop power.

Q: Is it possible to mix different variables, like pressure and flow, on the same module?

A: Absolutely. Since each channel is isolated and independently processed by the 3500/62 monitor, you can monitor any variable that provides a standard 4-20 mA signal on different channels.

Q: What is the warranty and origin of this part?

A: This is a genuine Bently Nevada product manufactured in the USA. It comes in brand-new condition with a 12-month warranty and is ready for immediate dispatch.
