The Allen-Bradley 1794-IB16XOB16P, also cataloged as the 1794-IB16XOB16P Flex 32 Point Digital Combination Module, operates as a dedicated hardware component for concurrent discrete input sensing and output actuation within FLEX I/O platforms. The assembly functions as a high-density, mixed-mode module interfacing directly with 24 VDC field equipment. It routes 16 sinking binary inputs and 16 electronically protected sourcing outputs through a standardized terminal base interface to the remote or local rack controller backplane.

Hardware Designation Profile

The alphanumeric code designates the physical density and internal electronics configuration of the combination board. The identifier "1794" enforces mechanical and signal compliance with the standard industrial FLEX I/O chassis matrix. The segment "IB16" defines 16 independent channels configured for direct current sinking operations, while the following string "XOB16P" specifies 16 sourcing direct current output channels equipped with integrated electronic short-circuit protection.

Technical Parameters

Density Scaling and Firmware Verification

The electronic architecture regulates synchronous signal processing across combined input and output matrices without degrading network data updates. The internal microcode functions within defined backplane bus communication velocity Licences profiles, preventing packet collision across the rack infrastructure. This hardware configuration permits multi-channel I/O density scaling inside localized control cells while matching factory electronic keying rules for firmware flash compatibility.

Shipping Kit Composition

• 1 x 1794-IB16XOB16P combination I/O module
• 1 x factory electrical installation reference guide

Substructure Mounting & Shielding Directives

• DIN Rail Engagement Lock

  Hook the upper retention slot of the IP20 housing over the top flange of the DIN rail, then snap the lower edge downward until the spring-loaded lock fastens onto the steel profile.

• Terminal Base Insertion Path

  Align the structural alignment keyways on the bottom of the module with the registration pin of the terminal base unit, pushing vertically until the multi-pin connector fully mates.

• DC Power and Signal Routing

  Strip the 24 VDC field wires and connect the sinking input leads and sourcing output leads to the designated terminal base channels, isolating the positive rail for the outputs.

• Equipotential Ground Path Verification

  Establish a direct low-impedance copper ground connection from the DIN rail track to the central cabinet enclosure grounding plate to eliminate common-mode high-frequency noise.

Frequently Asked Questions

• What specific boundaries govern the hot-swapping or RIUP capabilities of this combination module?

  Removal and Insertion Under Power is permitted when using a compatible terminal base, but field-side 24 VDC power loops must be physically isolated first to prevent electrical arcing across contacts.

• How does the integrated electronic protection react during a downstream short-circuit on an output point?

  The electronic short-circuit protection instantly trips the affected channel to a safe, non-conducting state, lighting the localized fault indicator and setting an internal data status flag.

• Does this mixed-mode configuration allow the grouping of sinking inputs and sourcing outputs on a single common line?

  No. Sinking inputs require the field device to switch the positive leg to the module, whereas sourcing outputs actively drive current out from the positive rail to the field load.

• What signature is recorded by the primary controller if the internal Flexbus logic current exceeds current limits?

  The system interface drops the module connection, logs a slot communication timeout fault inside the processor logic matrix, and forces all 16 sourcing outputs to an unpowered state.

• What procedure clears a latched electronic protection fault state after fixing a shorted field device?

  The external field short-circuit must be fully eliminated, and then the channel must be reset either through a programmatic controller command toggle or by cycling the module field power.

• How does maximum simultaneous channel activation impact the thermal dissipation limits of the IP20 chassis?

  Running all 32 points at continuous maximum load increases thermal output, requiring strict enforcement of the 55 deg C temperature limit and minimum physical layout clearances.

• Can this module be used with AC voltage field instruments if interposing terminals are absent?

  No. The module internal optocouplers and transistors operate exclusively on direct current 24 VDC loops; feeding alternating current into the module will cause catastrophic circuit failure.

• How is firmware flash compatibility handled between different assembly revisions of this module?

  The device features hardware-defined logic routing, meaning software compatibility is maintained by adjusting the electronic keying parameters within the main automation software configuration tree.
