The Allen-Bradley 1769-IM12, also cataloged as the 1769-IM12/A Digital Input Module, operates as a dedicated hardware component for 240V AC discrete signal detection within CompactLogix control networks.

Hardware Revision & Catalog Designation

• Standard Catalog Code: 1769-IM12
• Spare Revision Identifier: 1769-IM12/A
• System Platform: CompactLogix 1769 Expansion System
• Module Type: Non-isolated 12-Point AC Digital Input Card

Mechanical & Electrical Parameters

High-Density I/O Scaling & Deterministic Bus Transfer

Designed for high-density I/O scaling, the 1769-IM12 evaluates field contact status across 12 channels simultaneously and transfers discrete state tables over the 1769 local bus. Optimized backplane bus communication velocity maintains real-time input status synchronization with the CompactLogix controller while preserving internal firmware flash compatibility across systemic rack expansions.

Scope of Delivery

• 1 x 1769-IM12 AC Digital Input Module
• 1 x Removable Terminal Block Assembly
• 1 x Printed Module Installation Guide

Field Panel Mounting & Wiring Protocols

• Backplane Bus Shutdown: Isolate backplane power before attaching or removing the module from the CompactLogix assembly.
• DIN-Rail Engagement: Secure the unit onto the EN 50022 DIN rail using the integral mounting lock levers.
• Terminal Wiring Standard: Connect 159-265 VAC discrete field wiring to the plug-in terminal block, ensuring proper strain relief and shield routing.

Frequently Asked Questions

• Q: What operating voltage range does the 1769-IM12 support on its input channels?

  The input points accommodate 159 to 265 VAC discrete AC line signals at 47 to 63 Hz.

• Q: Are individual channels on the 1769-IM12 galvanically isolated from each other?

  No, the 12 input points share common circuit references and are classified as non-isolated.

• Q: Does the 1769-IM12 support hot-swapping under active backplane power?

  No, inserting or removing the module while the 1769 backplane is energized will disrupt bus communications and may cause hardware damage.

• Q: How is field wiring terminated on the front of the unit?

  Field connections attach via a plug-in removable terminal block assembly for modular servicing.

• Q: What hardware revision corresponds to the spare code 1769-IM12/A?

  The catalog variant 1769-IM12/A specifies a Series A hardware revision of the standard 1769-IM12 module.

• Q: What is the maximum operating ambient temperature for this input card?

  The unit is rated for operation in ambient enclosure temperatures ranging from 0 to 60 deg C.

• Q: How many discrete AC inputs are provided on a single card?

  The module provides 12 discrete AC input channels within a single 1769 slot footprint.

• Q: Can this module be installed in a remote 1769 expansion bank?

  Yes, it operates in local or remote 1769 expansion banks within power supply distance rating limits.
