The ABB AX552 1SAP250000R0001, also cataloged as the AX552 Analog Input/Output Module, operates as a dedicated hardware component for analog and digital signal processing within ABB AC500 Series automation platforms. The unit processes field signals across 8 configurable channels, interfacing directly with local terminal bases and controller backplanes. Operating at a nominal process voltage of 24 VDC, the module handles signal acquisition and command execution for process parameters while maintaining short-circuit and overcurrent protection via external fusing.

Technical Identifier Matrix

• Base Model: AX552
• Order Code: 1SAP250000R0001
• Brand: ABB
• Series: AC500 Platform
• Tariff Code: 8537101190
• Hardware Profile: 8-Channel Analog / Configurable I/O Module

Hardware Specifications

Backplane Bus Velocity and I/O Density Scaling

The ABB AX552 1SAP250000R0001 connects directly to the AC500 terminal base system, utilizing high-speed internal bus extension protocols to ensure deterministic cyclic scanning across all 8 configurable channels. High-density channel layout allows flexible mixed I/O configurations while limiting backplane power draw. Field-side isolation guards internal bus circuitry against line-induced voltage spikes. Microprocessor-driven onboard signal processing maintains fast conversion cycles and low latency communication with the AC500 CPU, preserving firmware flash compatibility and scan synchronization across local and decentralized I/O clusters.

Package Contents & Ordering Information

• 1x ABB AX552 1SAP250000R0001 Module Unit
• 1x Printed Terminal Base Compatibility Guide
• 1x Factory Quality Inspection Certificate

Field Installation Guidelines

• Mounting: Snap the module directly onto a compatible TU5xx Terminal Base attached to a 35 mm DIN rail. Secure mechanical latching clips to maintain proper pin alignment with backplane connectors.
• Wiring: Connect process supply voltage (24 VDC) and channel field devices using screw or spring-clamp terminals on the terminal base. Install a 10 A fast-acting fuse on the UP power supply line.
• Grounding: Ensure the DIN rail is electrically bonded to the functional ground (FG) plate using a heavy-duty copper braid or conductor. Ground resistance must measure under 100 ohms.
• Shielding: Use 360-deg braid-shielded twisted-pair cables for analog signal paths. Terminate cable shielding at the designated shield grounding clips on the terminal base.

Frequently Asked Questions

• What is the maximum allowed ripple voltage on the 24 VDC process supply line?

  The 24 VDC process voltage (UP) must not exceed a maximum AC voltage ripple of 5 % to maintain conversion accuracy.

• What type of external fuse protection is required on the UP power line?

  The UP supply line requires an external fast-acting fuse rated for a maximum current of 10 A.

• How many total configurable channels are provided on the AX552 module?

  The AX552 module contains 8 independent channels configurable for input/output operational modes.

• Does the module attach directly to the DIN rail or through a base component?

  The module mounts onto an AC500 TU5xx terminal base, which snaps onto a standard 35 mm DIN rail.

• Is hot-swapping supported for the AX552 module under power?

  Hot-swapping is restricted; field power supply UP and backplane power must be disabled before replacing the module to prevent electrical stress.

• What is the operating voltage range for the AX552 module inputs?

  The channel inputs operate at a nominal rating of 24 VDC within standard process tolerance windows.

• How are field signals shielded against electromagnetic interference?

  Field wiring must use 360-deg braid-shielded cables anchored to the grounding strip on the terminal base frame.

• What firmware requirement applies to the CPU when adding an AX552 module?

  The controller CPU firmware version must support the AC500 module hardware revision specified in Automation Builder software.
