Configured for serial synchronous encoder data acquisition in POINT I/O systems, the Allen-Bradley 1734-SSI (1734-SSI SSI Module) provides direct physical/electrical execution through a single SSI communication channel.

Model Identification & Configuration

The 1734-SSI is a Serial Synchronous Interface module designed for Allen-Bradley POINT I/O architecture. The module provides one SSI communication port for connecting SSI-compatible absolute position devices and transferring synchronous serial data through the POINTBus network.

Hardware Specifications

EtherNet/IP and POINTBus Data Integration

The 1734-SSI operates as a POINT I/O communication module within distributed I/O systems. The module exchanges SSI device data through the POINTBus backplane while maintaining modular I/O expansion capability.

The Allen-Bradley POINT I/O platform uses deterministic industrial communication methods for controller integration. Module configuration parameters are stored through the controller software environment and depend on the selected network adapter and controller architecture.

Firmware and I/O Configuration Compatibility

The module configuration requires matching firmware compatibility between the POINT I/O adapter, controller system, and installed I/O modules. Firmware flash compatibility should be verified before replacing modules in an active control architecture.

The 1734-SSI supports I/O density scaling through POINT I/O modular installation, allowing additional modules to be added according to system architecture requirements.

Ordering Information

The supplied configuration normally includes:

• 1 x Allen-Bradley 1734-SSI SSI Module
• 1 x POINT I/O module housing assembly

Additional components required for operation may include:

• POINT I/O terminal base
• Compatible POINT I/O adapter module
• Controller communication interface
• SSI field device wiring accessories

Field Installation Guidelines

Mechanical Installation

• Install the module on a compatible POINT I/O terminal base.
• Confirm module seating before applying system power.
• Maintain enclosure protection suitable for the installation environment.

SSI Signal Wiring

• Use wiring suitable for serial synchronous communication signals.
• Keep SSI communication wiring separated from high voltage conductors.
• Apply proper cable shielding and grounding practices where electrical interference exists.

System Commissioning

• Verify SSI device parameters before enabling data exchange.
• Confirm controller recognition of the module after installation.
• Check communication status indicators during commissioning.

Frequently Asked Questions

• What communication interface does the 1734-SSI support?

The module supports Serial Synchronous Interface communication for SSI-compatible devices requiring synchronous serial data transfer.

• How many SSI channels are available?

The 1734-SSI provides one dedicated SSI communication channel through the POINT I/O module structure.

• What supply voltage range is supported?

The module operates with a supply voltage range of 10 to 28.8 VDC according to the provided technical specifications.

• What is the POINTBus current requirement?

The module requires 110 mA of POINTBus current during operation within the POINT I/O system.

• What is the operating temperature range?

The specified operating temperature range is -20 to 55 deg C for normal module operation.

• Can the module be installed without a POINT I/O terminal base?

No. The module requires a compatible POINT I/O terminal base for mechanical mounting and electrical connection.

• Does the module support multiple SSI devices simultaneously?

No. The hardware configuration provides one SSI communication port for a single SSI device connection.

• What installation practices affect SSI signal quality?

Proper shielding, grounding, cable routing, and separation from electrical noise sources affect SSI communication stability.
