SKU: H3CR-A8E
Categories : All Products
In Stock
  • Dimensions: 58 mm x 58 mm x 95 mm
  • Country of origin: Japan
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The Omron H3CR-A8E 100/240VC, also cataloged as the H3CR-A8E Solid-State Timer, operates as a dedicated hardware component for time-delay switching and sequence control execution within industrial control panels.

Model Nomenclature & Functional Code

  • H3CR: DIN 48 x 48 mm solid-state timer module platform
  • A8: 8-pin socket connector physical interface configuration
  • E: Time-limit contact (SPDT) combined with instantaneous contact (SPDT) relay output
  • 100/240VC: 100 to 240 VAC wide-range supply voltage rating

Technical Parameter Specifications

Parameter Specification
Model H3CR-A8E 100/240VC
Brand Omron
Origin Japan
Weight 0.90 kg
Shipping Dimensions 58 mm x 58 mm x 95 mm
Operating Temp -10 deg C to 55 deg C
Power Consumption Approx. 2.1 VA max. (at 240 VAC)
Supply Voltage 100 to 240 VAC (50/60 Hz) / 100 to 125 VDC
Output Type SPDT time-limit relay + SPDT instantaneous relay
Physical Interface 8-pin round socket interface
Control Method Solid-state analog electronic timing circuit

Firmware Interfacing & Modular Control Performance

The module integrates seamlessly into discrete control circuits alongside distributed PLC platforms. Internal firmware flash compatibility and deterministic execution ensure high repeat accuracy during cyclic switching. High-density I/O density scaling allows synchronized multi-point relay tripping across centralized control cabinets while maintaining backplane bus communication velocity Licences across linked EtherCAT or EtherNet/IP remote sub-bus networks.

Standard Module Accessories

  • 1 x H3CR-A8E 100/240VC Solid-State Timer Unit
  • 1 x Front Panel Protective Setting Dial Ring
  • 1 x Terminal Pin Configuration Sheet

Cabinet Installation & Field Cabling Directives

Mounting Procedure

  • Insert the 8-pin base into an industrial P2CF-08 DIN-rail socket or track-mounting base until fully latched.
  • Ensure adequate spacing around panel cutouts to prevent thermal accumulation under continuous coil energization.

Wiring & Insulation Guidelines

  • Wire signal and supply leads securely to the 8-pin socket terminals using proper wire ferrules.
  • Separate AC control lines from low-voltage DC sensor cables to eliminate inductive switching noise interference.

Technical Inquiry Resolutions

  • What output contact arrangement is provided on the H3CR-A8E?

    The unit features one SPDT time-limit relay output and one SPDT instantaneous relay output.

  • What supply voltage range is accepted by this model?

    The unit operates on 100 to 240 VAC (50/60 Hz) or 100 to 125 VDC control power sources.

  • How is the physical electrical connection established?

    Connection is made via a standard 8-pin round plug-in base compatible with DIN-rail sockets.

  • Can time parameters be adjusted on the front panel?

    Time range selector switches and a rotary dial allow precise setting of delay timing ranges.

  • What precautions must be taken regarding hot-swapping?

    Power must be isolated from the socket before pulling or inserting the timer module assembly.

  • Is the relay output suitable for driving inductive loads?

    Inductive loads require external surge suppressors across contacts to prevent premature contact erosion.

  • How does the instantaneous contact function relative to coil power?

    The instantaneous SPDT contact transfers immediately upon coil energization regardless of time delay settings.

  • Does the timer retain setting accuracy under temperature variations?

    Solid-state timing circuits maintain high repeat accuracy across the ambient operational span of -10 deg C to 55 deg C.
