NX-PG0242-5 Omron NX Series Pulse Output Unit
Omron

NX-PG0242-5 Omron NX Series Pulse Output Unit

SKU: NX-PG0242-5
Categories : All Products
In Stock
  • Dimensions: 30 mm x 100 mm x 71 mm
  • Country of origin: Japan
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

Configured for open-loop positioning control and velocity manipulation in EtherCAT and NX bus motion systems, the Omron NX-PG0242-5 (NX-PG0242 Pulse Output Unit) provides direct physical/electrical execution via differential line driver signals.

Model Coding Structure & Terminal Configuration

  • PG0: Hardware category for pulse output units
  • 2: Dual-channel (2-channel) motion command architecture
  • 4: Line driver PNP type circuit specifications
  • 2: Synchronous I/O refreshing and task period prioritized refreshing capabilities
  • 5: Single MIL connector (34 terminals x 1) physical connection interface

Physical & Electrical Performance Parameters

Parameter Specification
Model NX-PG0242-5
Brand Omron
Origin Japan
Weight 0.11 kg
Shipping Dimensions 30 mm x 100 mm x 71 mm
Operating Temp 0 deg C to 55 deg C
Power Consumption Current consumption from I/O power supply: 50 mA max
Number of Channels 2
Pulse Output Type Line driver output (PNP type)
Max Pulse Velocity 1 to 4,000,000 pps
Position Range -2,147,483,648 to 2,147,483,647 pulses
Connection Method Single MIL connector (34 terminals x 1)
Cable Constraints Line driver output: 10 m max; Auxiliary I/O: 3 m max

High-Density Bus Interfacing & Synchronization

The module maintains synchronous data interchange over the backplane bus, enabling strict clock locking with the main motion controller. Optimized backplane bus communication velocity Licences prevent axis transmission jitter during multi-axis path synthesis. Onboard firmware flash compatibility permits field parameter deployment and runtime differential pulse modulation without restricting local I/O density scaling across adjacent rack positions.

Standard Module Accessories

  • 1 x NX-PG0242-5 Module Block
  • 1 x MIL Cable Connector Cover Assembly
  • 1 x Channel Designation Reference Sheet

System Integration & Wiring Rules

Mechanical Installation

  • Mount the unit directly onto a standard 35 mm DIN rail until the locking clip clicks securely into place.
  • Allow a minimum clearance of 30 mm above and below the enclosure to ensure proper natural thermal airflow.

Wiring & Cabling Guidelines

  • Connect field equipment through the 34-pin MIL connector interface using prefabricated cable assemblies.
  • Limit line driver signal cabling to 10 m max and auxiliary I/O connections to 3 m max to preserve signal integrity.

Frequently Asked Questions

  • What is the maximum pulse output rate generated per channel?

    The line driver output drivers deliver precision pulse strings at rates reaching up to 4,000,000 pps.

  • How are field signals wired to the module?

    All physical inputs and outputs interface through a single 34-terminal MIL connector located on the front face.

  • Which drive types can be controlled by this unit?

    It controls servo drives or stepper motor drives equipped with differential pulse string command inputs.

  • What signal forms can be generated on the pulse output pins?

    Channels support CW/CCW (forward/reverse), pulse + direction, or phase differential (x1/x2/x4) modes.

  • How many discrete I/O channels are provided per motion channel?

    Each channel features 5 dedicated external inputs, 2 differential pulse outputs, and 3 auxiliary outputs.

  • What cable length restrictions govern signal wiring?

    Differential line driver outputs support cable lengths up to 10 m max, whereas auxiliary I/O must remain within 3 m.

  • What I/O refreshing methods does this hardware support?

    It supports synchronous I/O refreshing and task period prioritized refreshing synced to the CPU cycle.

  • Can this module be unplugged while backplane power is applied?

    Power supplies to the NX backplane and I/O circuit must be switched off prior to installing or removing the unit.
