NX-ID6142-6 Omron NX Series Digital Input Unit
NX-ID6142-6 Omron NX Series Digital Input Unit
Omron

NX-ID6142-6 Omron NX Series Digital Input Unit

SKU: NX-ID6142-6
Categories : All Products
In Stock
  • Dimensions: 3 cm x 7.1 cm x 10 cm
  • Country of origin: Japan
  • Payment: T/T, Western Union
  • Shipping port: Xiamen
1 years warranty
Delivery time: 3-7 business days
Free 30 days return

Help

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

The Omron NX-ID6142-6, also cataloged as the NX-ID6142 Digital Input Module, operates as a dedicated hardware component for 24 VDC discrete signal conditioning within Sysmac NX automation networks. It provides 32 high-density digital input channels compatible with NPN or PNP field circuit topologies. Interfacing via a multi-pin Fujitsu connector, the unit utilizes Free-Run or Synchronous I/O refreshing methods to align input signal sampling directly with master processing cycles across the local backplane.

Hardware Nomenclature & Part Breakdown

  • NX: Modular Sysmac I/O series hardware platform designation.

  • ID: Discrete DC digital input module functional class.

  • 6: High-density 32-channel input capacity allocation.

  • 1: Bi-directional input circuit supporting both NPN and PNP sensor connections.

  • 42: Standard 24 VDC operating voltage rating with fast signal response characteristics.

  • -6: Front panel high-density Fujitsu connector interface type.

Technical Parameters & Operating Limits

Parameter Specification
Model NX-ID6142-6
Brand Omron
Origin Japan
Weight 0.09 kg
Shipping Dimensions 3.0 x 7.1 x 10.0 cm
Operating Temp 0 to 55 deg C
Power Consumption 0.90 W max (NX bus power) / 0.96 W max (I/O power)
Input Capacity 32 points
Nominal Voltage 24 VDC
Circuit Topology NPN / PNP bi-directional
Response Speed Exceeds 1 us (ON/OFF)
Refreshing Architecture Free-Run refreshing or Switching Synchronous I/O refreshing
Termination Interface Fujitsu Connector (-6 specification)

Deterministic Networking & Module Density

High I/O density scaling allows 32 distinct input signals to be processed within a single compact slice width, optimizing cabinet space in complex control systems. Operating over Profinet / EtherNet/IP deterministic networks, the module transmits real-time channel state data directly to the head coupler. Internal ASIC processing maintains rapid backplane bus communication velocity while ensuring cross-platform firmware flash compatibility across all Sysmac control systems.

Scope of Delivery

  • 1 x Omron NX-ID6142-6 Digital Input Module

  • 1 x Protective Dust Cover Cap for Fujitsu Connector Interface

Panel Assembly & Field Cabling Guidelines

  • DIN Rail Mounting: Engage top rail hooks onto a standard 35 mm DIN rail and push the module housing backward until the bottom latch snaps locked.

  • Fujitsu Connector Termination: Attach prefabricated, double-shielded harness assemblies to the front-facing Fujitsu connector plug.

  • Inter-Module Assembly: Align lateral mounting guide tracks with the adjoining NX slice and slide firmly sideways to lock backplane contacts.

  • Noise Suppression & Shielding: Connect cable braided shields directly to the panel functional ground bus bar using short grounding straps.

  • Supply Voltage Verification: Measure and confirm that external field power supplies output 24 VDC prior to energizing input signal loops.

Frequently Asked Questions

  • Is live hot-swapping supported for the NX-ID6142-6 on an energized backplane?

    No. You must turn off main controller power and external field power supplies before inserting or removing the module from the rack.

  • How are NPN and PNP sensor outputs wired to the unit?

    The bi-directional optocoupler inputs support both NPN (sinking) and PNP (sourcing) sensor configurations depending on common wiring terminal polarity.

  • What advantage does Synchronous I/O refreshing provide during runtime?

    Synchronous I/O refreshing locks input sampling precisely to the primary task cycle of the controller for deterministic data processing.

  • What protection is supplied for the unpopulated Fujitsu connector pins?

    A removable plastic protective dust cover cap is installed over the connector pins during factory shipping to prevent contamination.

  • Does the input hardware support high-frequency pulse detection?

    Yes. The internal hardware filtering circuit yields ON/OFF signal transition response speeds that comfortably exceed 1 us.

  • How does the internal bus maintain communication speed with 32 active channels?

    An internal processing ASIC packs all 32 channel digital states into a single unified bus data frame per refresh transmission cycle.

  • Can firmware flash compatibility be validated prior to online deployment?

    Yes. Software tools such as Sysmac Studio verify hardware revision codes against project profile files prior to code download.

  • Is external field power required to drive the module input circuits?

    Yes. An external 24 VDC power supply must be connected to power the field-side optical isolation loops and sensor circuits.
