The ABB GC C960 C102 3BHE033067R0102, also cataloged as the GC C960 C102 Drive Board, operates as a dedicated hardware component for analog reference processing and interface signal drive within AC 800PEC systems.

Module Designation & Model Mapping

• Base Hardware Model: GC C960 C102
• Manufacturing Part Number: 3BHE033067R0102
• Functional Classification: Drive Board
• Host Architecture: ABB AC 800PEC Control Platform

Physical & Electrical Performance Data

Deterministic Bus Interface & Firmware Synchronization

The GC C960 C102 module coordinates analog control loops with central processing logic over high-speed interface lines. Optimized backplane bus communication velocity allows rapid cyclical update rates without data collision. Embedded system configuration maintains strict firmware flash compatibility across AC 800PEC revisions, supporting dynamic I/O density scaling while preserving deterministic channel execution under full load conditions.

Standard Delivery Logistics

• 1 x ABB GC C960 C102 3BHE033067R0102 Drive Board
• Electrostatic protection packaging and anti-static wrapping

Field Cabinet Mounting & Wiring Directives

• Electrostatic Safety
  • Always wear grounded wrist straps prior to touching edge contacts or terminal headers to prevent ESD degradation.
• Mechanical Chassis Alignment
  • Insert card smoothly into dedicated rack guides to prevent pin deformation on internal backplane connectors.
• Signal Line Shielding
  • Ground analog input shielding (4-20 mA or 0-10 VDC) at single terminal grounding rails to suppress common-mode electrical noise.
• Auxiliary Power Integrity
  • Verify that nominal 24 VDC supply voltage remains within the strict +-10% tolerance band prior to powering up the assembly.

Technical Support FAQ

• What supply voltage limits are permitted for board operation?

  The board requires an auxiliary power source supplying 24 VDC within a +-10% tolerance range.

• What analog field signal standards does the board accept?

  The input channels accommodate standard process signals configured for 0 to 10 VDC or 4 to 20 mA.

• What physical vibration spectrum can the unit endure?

  The hardware withstands mechanical vibration frequencies across a range of 5 Hz to 150 Hz.

• What are the physical shipping footprint metrics for logistics?

  Package measurements are 44.8 cm in length, 17.3 cm in width, and 4.2 cm in height.

• What thermal parameters govern active operational environments?

  Operating ambient temperatures must remain strictly between -25 deg C and +55 deg C (-13 deg F to +131 deg F).

• How should analog loop cables be routed to avoid signal distortion?

  Route low-voltage analog wiring in separate grounded conduits away from three-phase motor AC cables.

• Can the drive board be hot-swapped while energized?

  Backplane DC power must be disconnected before board insertion or removal to prevent electrical arcing.

• What maximum non-condensing humidity level is allowed?

  Operating humidity levels must remain at or below 95% non-condensing.
