The ABB FEN-31 (68978840), also cataloged as the FEN-31 HTL encoder interface, operates as a dedicated hardware component for speed and position feedback processing within ABB ACS850 drive platforms.

Model Variant & Technical Identification

• Product Model: FEN-31

• Spare Part Number: 68978840

• Interface Type: HTL Encoder Interface Module

• Supported Signals: Differential push-pull, Single-ended push-pull, Open collector, Open emitter

System Parameters & Electrical Performance

Backplane Communication Velocity & Firmware Synchronization

The module interfaces directly with the drive control board via an internal high-speed system bus. Fast signal latching minimizes feedback phase delay during high-dynamic vector control loops. Firmware compatibility checks validate the module revision at startup, preventing bus execution in the event of version mismatch.

Delivery Package & Ordering Details

• 1 x FEN-31 HTL Encoder Interface Module (Part Number 68978840)

• 1 x Mounting hardware kit with grounding screws

• 1 x Installation instruction leaflet

Field Mounting & Wiring Standards

• Mechanical Slot Insertion

  Ensure drive main supply is completely powered off and DC bus capacitors are fully discharged before inserting the option module into its dedicated drive slot.

• Grounding and Shielding

  Connect the signal cable shield directly to the drive chassis grounding clamp to maintain high immunity against electromagnetic noise.

• Cable Routing Rules

  Route HTL encoder signal lines in separate conduits away from high-voltage motor output power leads to minimize capacitive coupling and cross-talk interference.

Technical Questions & Answers

• What encoder output configurations are supported by the module?

  The hardware directly accepts differential push-pull, single-ended push-pull, open collector, and open emitter HTL encoder signals.

• What voltage options are available for encoder supply power?

  The interface provides selectable auxiliary supply outputs of +15 VDC (+/- 20%) or +24 VDC (+/- 20%) up to a maximum current load of 200 mA.

• Can this option module be hot-swapped while the drive is energized?

  No. Insertion or removal of the module while power is applied can cause permanent damage to the module electronics and the drive control unit.

• How is the physical shield connection handled at the drive interface?

  The cable shield must be grounded at the drive end using the metal cable clamp provided with the module to establish 360 deg grounding.

• What physical dimensions are expected for transport packaging?

  The estimated shipping package measures approximately 35 cm x 11.7 cm x 3 cm with a total shipping weight of 0.38 kg.

• Does the interface require separate external power for HTL encoders?

  External power is not required if the encoder current draw remains below the 200 mA threshold provided by the internal supply outputs.

• What happens if the encoder supply output is overloaded?

  Internal overcurrent protection limits output supply current, which may result in encoder voltage drop and loss of feedback pulse tracking.

• What is the standard tariff code assigned to this spare part?

  The standardized customs tariff code for international customs clearance of this module is 8537101190.
