Configured for high-density register computation and multi-channel remote I/O link management in industrial control loops, the Allen-Bradley 1785-L80B (1785-L80B CPU Processor) provides direct physical/electrical execution across PLC-5 rack architectures.

Model Identification Matrix

  • Product Family: PLC-5
  • Product Model: 1785-L80B
  • Spare Model: 1785L80B
  • Module Type: CPU Processor Module
  • Memory Architecture: 100K Word SRAM
  • Country of Origin: United States
  • Tariff Code: 8537109060

Hardware Specifications

Parameter Specification
Model 1785-L80B
Brand Allen-Bradley
Origin United States
Weight 1.4 kg
Shipping Dimensions 5.1x12.7x27.9cm
Operating Temp 0 deg C to 60 deg C
Power Consumption Standard Backplane Draw
Total I/O Capacity 3072 (Supports Analog/Digital mix)
Communication Interfaces 4 DH+/Remote I/O Channels
Processor Type PLC-5/80 Central Processing Unit

Industrial Network Architecture & Bus Performance

Optimized for high-performance automation cells, the processor coordinates data exchanges through four integrated Data Highway Plus (DH+) and Remote I/O communication ports. Backplane bus communication velocity and firmware flash compatibility rely on stable electrical loading across the rack. I/O density scaling handles up to 3072 points with mixed analog and discrete support, maintaining deterministic update rates across extended link topologies.

Package Ordering Information

  • 1 x 1785-L80B PLC-5/80 Processor Module
  • 1 x Battery backup module component
  • 1 x Hardware configuration compliance document

Physical Insertion & Wiring Instructions

  • Backplane Insertion Protocols:
    • Align the module card edges precisely with the designated card guides on the PLC-5 chassis.
    • Push the unit firmly inward until the top and bottom mechanical locking levers snap securely into place.
  • Grounding & Shielding Execution:
    • Fasten heavy-duty copper bonding straps from the chassis ground lug to the cabinet earth bus bar.
    • Terminate all DH+ and Remote I/O communication cable shields at designated ground points to block electromagnetic interference.
  • Environmental & Thermal Management:
    • Maintain unobstructed vertical airflow paths around the chassis to prevent localized overheating.
    • Verify that cabinet internal temperatures stay within the specified operating limits during peak industrial load.

Frequently Asked Questions

  • Q: What is the total user memory capacity of the 1785-L80B processor?

    A: The module is equipped with a 100K Word SRAM memory structure for application logic and data storage.

  • Q: How many communication channels are embedded on this processor?

    A: The unit features 4 integrated channels capable of supporting Data Highway Plus (DH+) and Remote I/O protocols.

  • Q: What is the maximum I/O handling capacity for this controller?

    A: It supports a total of 3072 I/O points accommodating both analog and digital module configurations.

  • Q: Is hot-swapping permitted when installing or removing this module?

    A: No, backplane power must be completely disconnected before inserting or extracting the processor card.

  • Q: What physical dimensions characterize the shipping container size?

    A: The estimated shipping dimensions of the packaged hardware unit are 5.1x12.7x27.9cm.

  • Q: What is the total weight of the processor hardware module?

    A: The unit weighs approximately 1.4 kg excluding external packaging materials.

  • Q: What ambient operating temperature range is designated for this hardware?

    A: The processor functions reliably within an ambient temperature span ranging from 0 deg C to 60 deg C.

  • Q: What country serves as the manufacturing origin for this device?

    A: The hardware is manufactured and originated within the United States.
