ACS-CP-U 3AUA0000050961 ABB Control Panel ACS 850

SKU: 3AUA0000050961

In Stock

Dimensions: 23.4 cm x 22.5 cm x 3.8 cm
Country of origin: Sweden
Payment: T/T, Western Union
Shipping port: Xiamen

Categories : ABB, ABB HMI & Protection, All Products, DCS & Control Processors, HMI & Industrial Displays

Tags : ABB ACS 850, ACS 850, Drive Control Panels, Human Machine Interfaces, Inverter Control Hardware

1 years warranty

Delivery time: 3-7 business days

Free 30 days return

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

Configured for local parameter manipulation and drive status monitoring in ACS 850 variable frequency drives, the ABB ACS-CP-U 3AUA0000050961 (ACS-CP-U Control Panel) provides direct physical/electrical execution.

Model Nomenclature & Identification

Hardware Model: ACS-CP-U
Spare Part Number: 3AUA0000050961
Product Category: Operator Interface Panel
System Compatibility: ABB ACS 850 drive series control unit slot

Physical Parameters & Operating Limits

Parameter	Specification
Model	ACS-CP-U (3AUA0000050961)
Brand	ABB
Origin	Sweden
Weight	0.52 kg
Shipping Dimensions	23.4 x 22.5 x 3.8 cm
Operating Temp	-10 to +55 deg C
Storage Temp	-20 to +70 deg C
Power Supply	24 VDC
Power Consumption	Drawn directly from host drive controller (24 VDC)
Tariff Code	8537101190

Deterministic Network Bus & Firmware Interfacing

The ACS-CP-U panel communicates directly with the drive control board via an RS-485 serial connection over internal backplane architecture. The hardware configuration validates firmware flash compatibility during boot sequences to prevent communication mismatches. It allows real-time execution of parameter uploads, drive tuning, and status diagnostics across deterministic motor control networks.

Package Supply List

1 x ABB ACS-CP-U Control Panel (Part Number: 3AUA0000050961)
Protective anti-static packaging

On-Site Assembly & Wiring Protocols

Anti-Static Precaution Practices

Attach an earth-grounded ESD wrist strap prior to touching the panel body or rear connector pins.
Keep the operator interface inside electrostatic shielding material until immediate installation.

Mechanical Docking Procedure

Ensure host drive control unit is fully powered off or operating under safe maintenance protocols.
Align the mounting tabs on the rear of the ACS-CP-U panel with the panel slot on the ACS 850 drive housing.
Press the unit firmly into position until the snap-in locking mechanism fully engages the electrical bus connector.

Technical Support Queries

What is the primary input operating voltage required for panel operation?

The operator panel receives a regulated 24 VDC power supply directly through the internal drive connection.
What thermal limits must be maintained during active operation?

Operating ambient temperatures must remain strictly between -10 deg C and +55 deg C.
What storage conditions prevent component degradation?

Storage thermal levels must be kept within -20 deg C to +70 deg C in a non-condensing environment.
How does the control panel interface with the main drive processor?

The unit uses an internal serial link over the drive keypad interface port for bi-directional communication.
Can the ACS-CP-U panel be inserted while the drive is powered?

Hot-plugging is supported by the physical interface, though parameter changes require stable drive conditions.
What total weight is specified for shipment calculations?

The packaged unit has a net weight rating of 0.52 kg including protective shipping materials.
What overall dimensions are required for transit packaging?

The shipping box measures exactly 23.4 cm in length, 22.5 cm in width, and 3.8 cm in height.
How is firmware flash compatibility handled by the panel?

The control panel automatically queries the drive main control board firmware version upon boot initialization.
