ACN6340040500000300902 ABB Frequency Converter ACS 600

SKU: ACN6340040500000300902

In Stock

Dimensions: 46.2 x 36 x 7 cm
Country of origin: Sweden
Payment: T/T, Western Union
Shipping port: Xiamen

Categories : ABB, ABB Drives, All Products

Tags : ABB ACS 600, ACS 600, Frequency Converters

1 years warranty

Delivery time: 3-7 business days

Free 30 days return

If you have any questions, you are always welcome to contact us. We'll get back to you as soon as possible, withing 24 hours on weekdays.

Customer service

All questions about your order, return and delivery must be sent to our customer service team by e-mail at yourstore@yourdomain.com

Sale & Press

If you are interested in selling our products, need more information about our brand or wish to make a collaboration, please contact us at press@yourdomain.com

Configured for high-efficiency variable speed control in industrial automation networks, the ABB ACN6340040500000300902 (ACN6340040500000300902) Frequency Converter provides direct physical and electrical execution.

Nomenclature & Code Architecture

Platform Series: ABB ACS 600 industrial drive system architecture.
Part Catalog Identifier: ACN6340040500000300902 denoting unique firmware configurations, hardware layout matrices, and standardized output classifications.
Core Electronic Assembly: Integrated power rectifier, intermediate DC link circuit, and controlled IGBT inverter bridge.

Hardware Specifications Table

Parameter	Specification
Model	ACN6340040500000300902
Brand	ABB
Series	ACS 600
Origin	Sweden
Weight	8.6 kg
Shipping Dimensions	46.2 x 36 x 7 cm
Input	3-phase
Output Voltage (U2)	0 to U1 V
Rated Output Current (I2n)	47 A
Rated Motor Power	22 kW at 400 V
Output Frequency (f2)	0 to 300 Hz
Switching Frequency	4 kHz
Efficiency	Greater than or equal to 98 %
Operating Temperature	0 to 50 deg C
Storage Temperature	-40 to +70 deg C
Humidity	5 to 95 % RH non-condensing

Industrial Drive & System Processing Capabilities

The embedded controller handles real-time data exchange via backplane communication buses and network interface layers. Firmware flash compatibility ensures seamless integration with plant-wide Profinet or proprietary fieldbus platforms. Input/output density scaling is supported through modular extension slots, allowing deterministic execution of control algorithms without latency penalties.

Package Delivery Manifest

1 x ABB ACN6340040500000300902 Frequency Converter unit
1 x Plug-in terminal block connector assortment
1 x Installation hardware reference sheet

Physical Mounting & Wiring Directives

Cabinet Clearance: Secure the converter vertically inside an industrial enclosure, allowing minimum clearances of 200 mm above and below the chassis for unhindered airflow.
Power Termination: Connect incoming 3-phase lines to primary supply terminals using copper cables rated for continuous high-temperature exposure.
Shielded Cabling: Terminate motor output cables with 360-degree EMC metallic grounding clamps directly to the designated enclosure grounding bar.

Frequently Asked Questions

Q: What is the rated output current capacity of this frequency converter model?

A: The rated output current is 47 A, designed to support heavy motor loads efficiently.
Q: What is the maximum output frequency boundary for motor control?

A: The maximum output frequency reaches up to 300 Hz for high-speed applications.
Q: Does the unit support 3-phase input configurations?

A: Yes, the system requires a standard 3-phase input power supply architecture.
Q: What is the operational efficiency level of the inverter bridge?

A: The system achieves an operational efficiency rating of greater than or equal to 98 percent.
Q: What are the designated storage temperature limits?

A: The storage temperature range spans from -40 to +70 deg C under dry conditions.
Q: Is firmware flash compatibility maintained across system updates?

A: Yes, internal firmware supports standard flash updates via designated communication ports.
Q: How should control signal wires be routed relative to power cables?

A: Control wiring must be separated from high-voltage power cables by at least 300 mm to minimize electromagnetic noise coupling.
Q: What is the physical weight of the converter module?

A: The net weight of the hardware unit is 8.6 kg.
