Configured for gap distance measurement and vibration telemetry within rotating machinery setups, the Bently Nevada 330103-00-16-10-02-05 (330103-00-16-10-02-05 3300 XL 8 mm Proximity Probes) provides direct physical electrical execution.

Nomenclature Breakdown & Model Matrix

• 330103: Base product series identifier for 3300 XL 8 mm proximity probes.
• 00: Unthreaded length option indicating zero unthreaded portion.
• 16: Overall case length option indicating a 1.6-meter total length build or corresponding case layout variant.
• 10: Total cable length option specifying a 1.0-meter length configuration.
• 02: Connector and cable option designating standard coaxial connector configurations without armor.
• 05: Agency approval option indicating CSA, ATEX, and IECEx hazardous location certifications.

Hardware Specifications

Rotor Dynamics & Transducer Signal Engineering

Operating as an active eddy-current transducer front-end, the probe maintains precise eddy-current probe scaling to convert target gaps into proportional voltage outputs. It supports gap voltage validation targets near -10 VDC baselines, facilitating rotor dynamics tracking and cross-talk suppression across adjacent machinery channels without mutual interference.

Package Ordering Information

• 1 x 330103-00-16-10-02-05 3300 XL 8 mm Proximity Probe unit
• 1 x Integrated protective terminal cap set

Physical Installation & Mechanical Mounting Guidelines

• Housing Engagement: Thread the probe housing into the machine case or standoff adapter utilizing proper mechanical threads, ensuring secure seating.
• Standoff Clearance: Verify that any intermediate standoff adapter is tightly coupled to the machine casing to maintain proper insertion depth and clearance.
• Sleeve Support: Apply secondary sleeve support structures for probe penetrations exceeding 12 inches to suppress mechanical vibration resonance.

Frequently Asked Questions

• Q: What is the nominal tip diameter of the 330103-00-16-10-02-05 proximity probe?

  A: The probe features a standard 8 mm diameter sensing tip.

• Q: What unthreaded length is specified for this particular model code?

  A: The unthreaded portion is designated as zero for this configuration.

• Q: What total cable length is included with this probe configuration?

  A: The integrated cable length is 1.0 meter.

• Q: What hazardous area certifications apply to this specific part number?

  A: The unit carries CSA, ATEX, and IECEx hazardous location agency approvals.

• Q: What physical operating temperature limits apply to this sensor?

  A: The probe functions within a temperature range of -35 deg C to +177 deg C.

• Q: What is the pull strength rating of the internal cable attachment?

  A: The CableLoc design provides a 330 N (75 lbf) pull strength.

• Q: Does this model require component matching during replacement?

  A: No, 3300 XL components support complete interchangeability without bench calibration.

• Q: What electrical output does the transducer system generate?

  A: It outputs a voltage directly proportional to the distance between the probe tip and the target.
