Configured for acceleration signal transmission between Bently Nevada accelerometers and monitoring circuits, the Bently Nevada 130539-30 (130539-30 Interconnect Cable) provides direct electrical connection for 330400 and 330425 vibration measurement systems.

Model Identification

The 130539-30 is a three-conductor shielded interconnect cable assembly designed for Bently Nevada accelerometer installations. The cable uses 18 AWG (1.0 mm2) conductors with a 3-socket plug and fluorosilicone elastomer boot at one end and terminal lug termination at the other end.

The cable assembly supports connection between accelerometer field sensors and vibration monitoring equipment where casing acceleration signals require controlled transmission characteristics.

Hardware Specifications

Rotor Dynamics Signal Transmission Characteristics

The 130539-30 cable assembly is designed for vibration monitoring signal paths where shielding, impedance control, and conductor configuration influence measurement accuracy. The shielded construction supports suppression of external electrical interference affecting acceleration signal transmission.

For Bently Nevada machinery monitoring systems, correct cable installation assists rotor dynamics evaluation by maintaining the electrical characteristics between the accelerometer and monitoring input channel. The cable is associated with casing acceleration measurement circuits used with 330400 and 330425 accelerometer platforms.

Ordering Information

The standard package contents include:

• 1 x Bently Nevada 130539-30 Accelerometer Interconnect Cable
• 1 x 3-socket plug with fluorosilicone elastomer boot
• 1 x Terminal lug termination assembly

Compatible components may include:

• Bently Nevada 330400 Accelerometer
• Bently Nevada 330425 Accelerometer
• Machinery vibration monitoring systems

Field Installation Guidelines

Cable Connection

• Connect the 3-socket plug to the compatible accelerometer receptacle.
• Verify correct terminal lug assignment before system energization.
• Ensure connector engagement is complete before mechanical operation.

Signal Wiring Practice

• Route the cable away from high-voltage switching conductors.
• Maintain shield grounding according to the vibration monitoring system design.
• Avoid unnecessary cable loops near electromagnetic noise sources.

Mechanical Protection

• Prevent excessive bending force at the connector boot area.
• Secure the cable to reduce vibration-induced movement.
• Inspect insulation and termination points before commissioning.

Frequently Asked Questions

• What accelerometer systems are compatible with the 130539-30 cable?

  The cable is specified for Bently Nevada 330400 and 330425 accelerometer systems requiring three-conductor shielded connections.

• What is the conductor configuration of this cable?

  The assembly uses three shielded conductors with 18 AWG (1.0 mm2) wire construction.

• What is the rated operating temperature range?

  The operating temperature range is -55 to +200 deg C, with storage capability from -60 to +205 deg C.

• What connector type is installed on the cable?

  The cable includes a 3-socket plug with a fluorosilicone elastomer boot on one end.

• What is the characteristic impedance of the cable?

  The specified impedance is 100 Ohm with a tolerance of +/-5%.

• Is the 130539-30 cable suitable for proximity probes?

  No. This cable is intended for accelerometer signal connections and is not specified for eddy-current probe circuits.

• What is the cable length of this model?

  The 130539-30 model has a specified length of 30 ft (9.14 m).

• Why is cable shielding used in this application?

  Shielding reduces external electrical interference coupling into vibration measurement signal paths.
